Key Features

• Ultra-fast Maximum Power Point Tracking (MPPT).
• Advanced Maximum Power Point Detection in case of partial shading conditions.
• Outstanding conversion efficiency.
• Flexible charge algorithm.
• Extensive electronic protection.
• Internal temperature sensor.
• Real-time data display options.

Technical Specifications

• Battery voltage: 12V/24V/48V Auto Select (software tool needed to select 36V).
• Rated charge current: 35A.
• Maximum PV power, 12V: 500W, 24V: 1000W, 36V:1500W, 48V: 4900W.
• Max. PV short circuit current: 40A.
• Maximum PV open circuit voltage: 150V absolute maximum coldest conditions. 245V start-up and operating maximum.
• Maximum efficiency: 98%.
• Self-consumption: Less than 10mA.
• Charge voltage 'absorption': Default setting: 14,4V/28,8V/43,2V/57,6V (adjustable with: rotary switch, display, VE. Direct or Bluetooth).
• Charge voltage 'float': Default setting - 13,8V/27,6V/41,4V/55,2V (adjustable: rotary switch, display, VE. Direct or Bluetooth).
• Charge algorithm: multi-stage adaptive.
• Temperature compensation: -16 mV / -32 mV / -68 mV / °C.
• Protection: Battery reverse polarity (fuse, not user accessible) / PV reverse polarity / Output short circuit / Over temperature.
• Operating temperature: -30 to 60°C (full rated output up to 40°C).
• Humidity: 95%, non-condensing.
• Dimensions (TR Version): 130 mm x 186 mm x 70 mm.
