At Aims Power, We’re Passionate About Designing And Developing Off-grid And Renewable Energy Solutions.
AIMS Power 1500 Watt Pure Sine Low Frequency Inverter with built-in battery charger and transfer switch. This inverter charger is perfect for small-sized industrial applications that depend upon power being available even under heavy load. This heavy-duty inverter charger is ready to go wherever you need it. Use this product for renewable solar, off-grid home and business back up power, mobile and emergency backup power applications anywhere that uses 110 or 120 volts of alternating current.
See Features Below:
-
Listed to UL 458 Standards and CSA 22.2 No 107.1
-
1500 watt low frequency inverter
-
4500 watt surge for 20 seconds -3x surge capability
-
Battery priority selector
-
AC direct connect terminal block
-
GFCI - 20amps
-
Marine coated and protected
-
Multi stage smart charger 50 Amp for gel, AGM, lead and lithium LiFePO4
-
Remote panel available
-
Auto gen start
-
Auto frequency
-
10msec typical transfer time
-
7 battery type settings for charger
-
Selectable 25W power save mode (hibernation)
-
Automatic transfer switch
This inverter is also great in a smaller RV or boat. If 1500 watts is not enough power, check out our full line of low frequency inverter chargers available in 12, 24 & 48 volt versions. This AIMS power inverter charger is capable of accepting any source of 120v AC power to charge batteries, including a gas or diesel generator or shore power at an RV park/truck stop. It will even accept power from an extension cord plugged into your wall outlet at home.
Specifications
Inverter Output Specifications | |
---|---|
Listed to UL 458 Standards | |
Continuous Output Power | 1500 Watts |
Surge Rating | 4500 Watts (20 Seconds) |
Output Waveform | Pure Sine/Same as input (Bypass Mode) |
Output Voltage | 100-110-120Vac |
Nominal Efficiency | >92% (Peak) |
Line Mode Efficiency | >95% |
Output Frequency | 50Hz /- 0.3Hz / 60Hz /- 0.3Hz |
Bypass Terminal Breaker - 20 amps | |
Typical Transfer Time | 10ms (Max) |
THD | < 10% DC |
Input Specifications | |
Nominal Input Voltage | 12.0Vdc |
Minimum Start Voltage | 10.0Vdc |
Low Battery Alarm | 10.5Vdc-11.0Vdc |
Low Battery Trip | 10.0Vdc-10.5Vdc |
High Voltage Alarm | 16.0Vdc |
Low /battery Voltage Restart | 13.0Vdc |
Idle Consumption | 13.5 watts |
Charger Breaker - 20 amps | |
Power Saver Mode Idle Consumption | 8 watts |
Charger Specifications | |
Output Voltage | Depends on battery Type |
Charger Rate | 50A |
Dimensions | |
Unit Weight | 38 lbs. |
Unit Size L x W x H | 15.35 x 11 x 7 inches |
Shipping Weight | 46 lbs. |
Shipping L x W x H | 20.5 X 13.8 X 12.2 inches |
Product Manual
